XLA 170 The XLA 170 high performance Multi Format fully Automatic Slicer Positioning Technical Specifications Max cutting width: 170cm/67in. Min cutting width: 28cm/11in. Max roll diameter allowed: 26cm – 80Kg | 60cm – 200Kg with Heavy Duty accessory (optional) | 60cm – 400Kg con JRU170 (optional) Max cutting thickness: 1mm Feeding speed: 18mt/min RIP Support: Caldera V12 Print Factory Onyx X cutting accuracy: 1mm Y slicer positioning accuracy: 0.2mm Net Weight: 275Kg Gross Weight: 550Kg Dimensions: 281x87x110h Shipping Dimensions: 303x103x145h
Click to Download XLA170 PDF
The XLA170 is the world’s first fully automatic X-Y cutter from Fotoba with automatic positioning of the vertical slicing units. The XLA170 reads the barcode printed on the media by the Caldera V12 RIP, instructing the machine to precisely position the vertical slicers automatically. This machine is therefore suitable for multi format jobs to be nested on the roll during printing, to optimise the use of the media.
Touch Screen Setup for all Functions Barcode Reading for Slicer Position Automatic Slicer Positioning on the Fly
it is the perfect solution to trim up to 1mm thick flexible media up to 1,7 mt/67in in width. Regardless of any feed misalignment, the XLA 170 will automatically re-align itself to the edge of the printed image. If the printer fails to print parallel to the media edge, or if the printer fails to wind up the roll squarely, the XLD170 True Edge Tracking always produces perfectly squared posters. The XLA 170 cutters can handle most flexible media up to a maximum thickness of 1mm including polycarbonate, photo paper, vinyl, self-adhesive vinyl, PVC, film, duratrans, TDF, canvas, laminated or encapsulated prints and much more. Fotoba XLA170 Fully Automatic Wide Roll Cutter
The Caldera V12, Print Factory and Onyx RIPs print a barcode that describes to the XLA170 the precise positioning for the vertical slicing units. Changing from one format to another within the roll takes less than a couple of seconds allowing easy handling of different size formats within the same roll. The Fotoba XLA170 if far quicker than cutting multi format jobs on any Flatbed CNC cutter, due to the cutting process being continuous.
